Ecolite 102 V2 Ultra Low Profile LED Downlight

  • $36.57

✔ 1-2 business day dispatch.


why_shop_with_us

The perfect 32.7mm low profile design with tri-colour switch on the back for commercial or residential applications. Focused towards a comfortable, efficient and adjustable lighting design.

Suited for tight ceiling cavities, sloped or pitched ceilings requiring gimbal design and low power consumption. A far better option compared to traditional flush mount LEDs which are common used within the home building industry

Built with visual comfort in mind, the new Ecolite 102 features a low-glare recessed LED, effectively hiding the light source from the viewer’s direct line of sight. Its low glare design is complimented by its 60° beam angle, ensuring it seamlessly integrates within your ceiling.



Working well in general area lighting, artwork or architectural feature highlighting.

SPECIFICATIONS
Wattage 8W
Dimmable Yes (refer to driver specs below)
Beam angle

60°

CutoutØ 90mm
Gimbal
20° adjustment
Power factor >90
IP factor IP20
IC rating IC-4
Input Voltage 240V 50-60Hz
Warranty 3 Year
Dimensions D111mm x H32.7mm
Cable (300mm light to driver + 600mm driver to plug)
LED INFORMATION
LED chip type COB
Lumens @ 3000K

640lm

(4K=720lm 57K=720lm)

Efficacy 80 lm/W*approx
CCT

3000K / 4000K / 5700K

CRI rating

80

Lifetime 30,000 Hours
MATERIALS & FINISHES
Colour options White
Material Housing & Heatsink Plastic + Aluminium
Diffuser clear polycarbonate
DRIVER INFORMATION
Driver Spec

Constant Current:

Dimmable with trailing edge dimmer.

Suitable for 2-way switching

Suitable for use with PIR & Microwave sensors

Compatible Dimmers

Clipsal: 32E450TM, 32ELEDM

HPM: CAT400T

Diginet: MEDM, MMDM/RT

1-10 units

Driver type External
Lead type flex with plug
